Sicoma Concrete Mixer
-
Mixer Capacity: 2.0m3, 3.0m3, 4.0m3
-
Aggregate Size: 60/80
-
Aggregate Category: 4
-
Lubrication System: Choose
Description
1.Description of SICOMA Concrete Mixer:
(1). Powerful compulsory spiral mixing action throws particles from each side of the mixer towards the center, where they combine;
(2). The water is forced through powerful jets into the mix, where it is absorbed completely, allowing the cement slurry to coat all the aggregate particles uniformly, forming the strongest concrete.
(3). Air purged multi seals to enhance bearing life and effectively avoid slurry leakage.
(4). Unique monitoring system to monitor the running conditions of gearbox.
(5). Automatic multi pump units for shaft lubrication, special pump pin unit design.
2. The Features of Sicoma Concrete Mixer:
(1). Multi pipes water spraying system to ensure fast and thorough mixing.
(2). Optional weighing system
(3). High pressure cleaning system
Specification
1.The Parameters of Sicoma Concrete Mixer 2.0m3
Specification | Value |
Discharging Volume | 2000 |
Charging Volume | 3000 |
Mixer Capacity | 2 |
Lubrication System | Choosed |
Reducer | Choosed |
Aggregate Size | 60/80 |
Aggregate Category | 4 |
Working Circle | 60 |
Mixer Motor Power | 2x37 |
Mixing Speed | 35.5 |
Mixing Blade(Quantity) | 2x8 |
Lifting Motor Power | 21 |
Pump Motor Power | 3 |
Weight | 7500 |
Dimensions | 2400x3500x2175 |
2.The Parameters of Sicoma Concrete Mixer 3.0m3
Specification | Value |
Discharging Volume | 3000 |
Charging Volume | 4500 |
Mixer Capacity | 3 |
Lubrication System | Choosed |
Reducer | Choosed |
Aggregate Size | 60/80 |
Aggregate Category | 4 |
Working Circle | 60 |
Mixer Motor Power | 2x55 |
Mixing Speed | 35.5 |
Mixing Blade(Quantity) | 2x9 |
Lifting Motor Power | 25 |
Pump Motor Power | 3 |
Weight | 9200 |
Dimensions | 2680x3830x2175 |
3.The Parameters of Sicoma Concrete Mixer 4.0m3
Specification | Value |
Discharging Volume | 4000 |
Charging Volume | 6000 |
Mixer Capacity | 4 |
Lubrication System | Choosed |
Reducer | BONFIGLIOLI |
Aggregate Size | 60/80 |
Aggregate Category | 4 |
Working Circle | 60 |
Mixer Motor Power | 2x75 |
Mixing Speed | 31.5 |
Mixing Blade(Quantity) | 2x11 |
Lifting Motor Power | 28 |
Pump Motor Power | 3 |
Weight | 11800 |
Dimensions | 2680x4435x2175 |
