Products

+-

JS1500 Concrete Mixer

  •

    Mixer Capacity: 1.5m3

  •

    Discharging Volume: 1500L

  •

    Charging Volume: 2400L

  •

    Mixer Motor Power: 45kw

Description

1.Description of JS1500 Concrete Mixer:

(1). JS1500 compulsory concrete mixer discharge every 1.5 square, also known as 1.5 square compulsory concrete mixer is developed from our factory according to SICOMA forced mixing console combined with domestic users.

(2). The concrete mixer features a high efficiency forced mixing console. As usual HZS75, HZS90 mixing station or host station.

(3). The aircraft has a separate stand-alone operation and dual superiority. The PLD concrete batching machine composed of commodity concrete mixing station, which is widely used in medium and large precast plant and highways, bridges, water , terminals and other industrial and civil engineering.

2. Applications and Features of JS1500 Concrete Mixer:

JS1500 concrete mixer (HZS75 concrete batching plant for sale, HZS90 mixed concrete batching plant) applies to all types of large, medium and small prefabricated factories and roads, bridges, water conservancy, port and other industrial and civil engineering, which can mix dry concrete, plastic concrete, fluidity concrete, lightweight aggregate concrete and all kinds of mortar. The product design is reasonable structure, innovative layout, ease of use and maintenance.

Specification

The Parameters of JS1500 Concrete Mixer:

JS1500 Concrete Mixer

Specification

Value

Productivity

75m3/h

Discharging Volume

1500l

Charging Volume

2400l

Mixer Capacity

1.5m3

Aggregate Size

60/80mm

Working Circle

60sec

Mixer Motor Power

45kw

Lifting Motor Power

18.5kw

Pump Motor Power

3kw

Weight

10000kg

Dimensions

4500x2250x3000mm

Drawing
